I learned to program with gcc, C++, and vim. When I started working with C# and .NET, clicking the “Start” button in Visual Studio was magical, but also dissatisfying. Dissatisfying – not because I want to write a Makefile – but because I didn’t know what “Start” did. So, I started to dig. In this post, I’ll show the most primitive tools used in .NET Core, and manually create a .NET Core app without the help of Visual Studio. If you’re new to .NET Core and want to peek under the hood, this is a good post for you. If you’re already a .NET Core developer and wonder what *.deps.json or *.runtimeconfig.json files are all about, I’ll cover those, too.

I’m going to abandon the magic of Visual Studio and stick to command-line tools. To play with this yourself, you’ll need the .NET Core 2.1 SDK. These steps were written for macOS, but they work on Linux and Windows, too, if you adjust file paths to C:\Program Files\dotnet\ and dotnet.exe.

See also Part 2 if you want to keep learning out .NET Core’s inner workings.

The C# Compiler

The C# compiler turns *.cs files into a *.dll file, aka an assembly file. An assembly file is a portable executable format which .NET Core can run on Windows, macOS, and Linux. A “.NET Core app” is really just a collection of the *.dll files (and a few config files.) It can be produced using multiple programming languages like VB or F#, but C# is most commonly used.

The C# compiler can be invoked directly to produce an assembly file. The C# compiler can be found in the .NET Core SDK and can be invoked directly like this:

> dotnet /usr/local/share/dotnet/sdk/2.1.3/Roslyn/bincore/csc.dll -help

Let’s give it input. First, write this C# code into a file named “Program.cs”.

/* Program.cs */
class Program
{
    static void Main(string[] args)
        => System.Console.WriteLine("Hello World!");
}

On the command-line, execute this command.

> dotnet \
  /usr/local/share/dotnet/sdk/2.1.3/Roslyn/bincore/csc.dll \
  -reference:/usr/local/share/dotnet/sdk/NuGetFallbackFolder/microsoft.netcore.app/2.0.0/ref/netcoreapp2.0/System.Runtime.dll \
  -reference:/usr/local/share/dotnet/sdk/NuGetFallbackFolder/microsoft.netcore.app/2.0.0/ref/netcoreapp2.0/System.Console.dll \
  -out:Program.dll \
  Program.cs

Explaining the arguments:

  • dotnet - the C# compiler is itself a .NET Core application, so we must launch it by using dotnet.
  • /usr/local/share/dotnet/sdk/2.1.3/Roslyn/bincore/csc.dll - the path to the C# compiler. This is found in C:\Program Files\dotnet\ on Windows.
  • -reference args pointing to System.Runtime.dll and System.Console.dll - these are like “header” files. They provide the compiler with information about “System.Object” and “System.Console”.
  • -out:Program.dll - the output file name. The .dll extension is a .NET Core convention, not a requirement. If not specified, the compiler will produce a file named Program.exe. On Windows, this would be a little misleading becase you can’t double-click Program.exe, so in .NET Core we always use .dll.
  • Program.cs - the path to your C# file

References allow your code to use types defined by others. .NET Core defines thousands of types that you can use, like List<T>, Integer, and HttpClient, but you have to tell the compiler where to find these. If you were to drop the -reference arguments, the compiler would fail with:

Program.cs(1,11): error CS0518: Predefined type 'System.Object' is not defined or imported
Program.cs(3,26): error CS0518: Predefined type 'System.String' is not defined or imported
Program.cs(3,16): error CS0518: Predefined type 'System.Void' is not defined or imported

The path in the sample is /usr/local/share/dotnet/sdk/NuGetFallbackFolder/microsoft.netcore.app. This happens to come from the Microsoft.NETCore.App NuGet package, but we’ll get to that later.

runtimeconfig.json

The runtimeconfig.json file is required for .NET Core applications. The terms “runtime”, “shared framework”, or “platform” are often used interchangeably, but they typically mean the same thing when talking about .NET Core. This JSON file configures options for the runtime.

If you have the assembly file from the last step, you could attempt to run it on command-line by calling dotnet. Without a runtimeconfig.json file, this will fail with.

> dotnet Program.dll
A fatal error was encountered. The library 'libhostpolicy.dylib' required to execute the application was not found in '/Users/nmcmaster/code/'.

In English, this means that .NET Core could not find some of the required pieces of .NET Core used to execute the Program.dll file. To resolve this, create a file named Program.runtimeconfig.json with these contents:

{
  "runtimeOptions": {
    "framework": {
      "name": "Microsoft.NETCore.App",
      "version": "2.0.0"
    }
  }
}

These options instruct dotnet to use the Microsoft.NETCore.App 2.0.0 shared framework. This framework is the most common one used, but others exist, such as Microsoft.AspNetCore.App. Unlike .NET Framework, which is machine-wide, there may be multiple .NET Core shared frameworks installed on a machine. dotnet will read the JSON file and look in /usr/local/share/dotnet/shared/$FrameworkName/$Version/ for the required files to run the application.

Aside: if a higher patch version of Microsoft.NETCore.App is installed, such as shared/Microsoft.NETCore.App/2.0.4/, dotnet will automatically pick the higher version.

Now, execute dotnet Program.dll.

> dotnet Program.dll
Hello world!

Packages

Packages provide a way to share code between projects, teams, and organizations. .NET assemblies are bundled into *.nupkg files, which are just ZIP archive files with an XML file (.nuspec) that contains metadata about the package.

The most popular package for .NET is called JSON.NET, aka Newtonsoft.Json. It provides API for JSON parsing/serialization. We can acquire this package from NuGet.org and extract it to disk.

# Bash
mkdir -p ./packages/Newtonsoft.Json/10.0.3/
curl -L https://www.nuget.org/api/v2/package/Newtonsoft.Json/10.0.3 | tar -xf - -C ./packages/Newtonsoft.Json/10.0.3/
# Windows (powershell)
mkdir ./packages/Newtonsoft.Json/10.0.3/
Invoke-WebRequest https://www.nuget.org/api/v2/package/Newtonsoft.Json/10.0.3 -OutFile Newtonsoft.Json.10.0.3.zip
Expand-Archive Newtonsoft.Json.10.0.3.zip -D ./packages/Newtonsoft.Json/10.0.3/

To demo its use, we’ll update the sample from the previous step to print our message as a JSON object.

class Program
{
    static void Main(string[] args)
      => System.Console.WriteLine(
          Newtonsoft.Json.JsonConvert.SerializeObject(new { greeting = "Hello World!" }));
}

Add more references to the compiler arguments to gain access to Newtonsoft.Json APIs.

> dotnet /usr/local/share/dotnet/sdk/2.1.3/Roslyn/bincore/csc.dll \
    -reference:/usr/local/share/dotnet/sdk/NuGetFallbackFolder/microsoft.netcore.app/2.0.0/ref/netcoreapp2.0/System.Runtime.dll \
    -reference:/usr/local/share/dotnet/sdk/NuGetFallbackFolder/microsoft.netcore.app/2.0.0/ref/netcoreapp2.0/System.Console.dll \
    -reference:/usr/local/share/dotnet/sdk/NuGetFallbackFolder/microsoft.netcore.app/2.0.0/ref/netcoreapp2.0/System.Collections.dll \
    -reference:./packages/Newtonsoft.Json/10.0.3/lib/netstandard1.3/Newtonsoft.Json.dll \
    -out:Program.dll \
    Program.cs

Aside: it should be obvious why we needed -reference:Newtonsoft.Json.dll, but why did we need System.Collections.dll? This is required because because we used an anonymous type, new { greeting }. Under the hood, the C# compiler generated a .Equals method on this anonymous type that invokes System.Collections.Generic.EqualityComparer<T>, which is defined in System.Collections.dll.

The compiler should succeed, though with a few warnings.

Program.cs(4,35): warning CS1701: Assuming assembly reference 'System.Runtime, Version=4.0.20.0, Culture=neutral, PublicKeyToken=b03f5f7f11d50a3a' used by 'Newtonsoft.Json' matches identity 'System.Runtime, Version=4.2.0.0, Culture=neutral, PublicKeyToken=b03f5f7f11d50a3a' of 'System.Runtime', you may need to supply runtime policy

This means that when the author of Newtonsoft.Json created Newtonsoft.Json.dll, he compiled it against System.Runtime.dll that was Version=4.0.20.0. But the System.Runtime.dll file we provided is newer, Version=4.2.0.0. The compiler is warning because there could be issues when you run the application if there were big changes between 4.0.20.0 and 4.2.0.0. Fortunately, these changes are all backwards compatible, so Newtonsoft.Json will work just fine. We can suppress this warning by adding -nowarn:CS1701.

> dotnet /usr/local/share/dotnet/sdk/2.1.3/Roslyn/bincore/csc.dll \
    -reference:/usr/local/share/dotnet/sdk/NuGetFallbackFolder/microsoft.netcore.app/2.0.0/ref/netcoreapp2.0/System.Runtime.dll \
    -reference:/usr/local/share/dotnet/sdk/NuGetFallbackFolder/microsoft.netcore.app/2.0.0/ref/netcoreapp2.0/System.Console.dll \
    -reference:/usr/local/share/dotnet/sdk/NuGetFallbackFolder/microsoft.netcore.app/2.0.0/ref/netcoreapp2.0/System.Collections.dll \
    -reference:./packages/Newtonsoft.Json/10.0.3/lib/netstandard1.3/Newtonsoft.Json.dll \
    -nowarn:CS1701 \
    -out:Program.dll \
    Program.cs

Dynamic Linking

In the previous step, we compiled a simple application that references Newtonsoft.Json.dll, System.Runtime.dll, and others. Before adding Newtonsoft.Json.dll, our application worked just fine. But with the updated version, the app will fail to run.

> dotnet Program.dll
Unhandled Exception: System.IO.FileNotFoundException: Could not load file or assembly 'Newtonsoft.Json, Version=10.0.0.0, Culture=neutral, PublicKeyToken=30ad4fe6b2a6aeed'. The system cannot find the file specified.

.NET is a dynamically linked runtime. The compiler adds a reference to Newtonsoft.Json.dll in the Program.dll assembly file , but does not duplicate its code. The .NET Core runtime expects to be able to load a file named Newtonsoft.Json.dll when the application is executed. The same is true for System.Runtime.dll, System.Console.dll, and the other System.* files we specified as references.

.NET Core can be configured to look for Newtonsoft.Json.dll in a variety of locations, but for simplicity, we can copy this into the same directory as Program.dll.

> cp ./packages/Newtonsoft.Json/10.0.3/lib/netstandard1.3/Newtonsoft.Json.dll ./
> dotnet Program.dll
{"greeting":"Hello World!"}

Why didn’t we need to copy System.Runtime.dll and others? These files were dynamically linked from the Microsoft.NETCore.App shared framework, as explained above in runtimeconfig.json section.

deps.json

The deps.json file is a dependencies manifest. It can be used to configure dynamic linking to assemblies that come from packages. As mentioned above, .NET Core can be configured to dynamically load assemblies from multiple locations. These locations include:

  • App base directory (in the same folder as the entry point application, no config required)
  • Package cache folders (NuGet restore cache or NuGet fallback folders)
  • An optimized package cache or runtime packages store
  • The servicing index (rarely used. For Windows Update purposes.)
  • Shared framework (configured via runtimeconfig.json)

Among other things, the deps.json file defines a list of dependencies that can be dynamically linked. Normally, this file is machine-generated, and can get really big and complicated for a real-world app. But, it’s plaintext, so we can craft it with just an editor.

Add a file named Program.deps.json into your project with these contents.

{
  "runtimeTarget": {
    "name": ".NETCoreApp,Version=v2.0"
  },
  "targets": {
    ".NETCoreApp,Version=v2.0": {
      "Newtonsoft.Json/10.0.3": {
        "runtime": {
          "lib/netstandard1.3/Newtonsoft.Json.dll": {
            "assemblyVersion": "10.0.0.0",
            "fileVersion": "10.0.3.21018"
          }
        }
      }
    }
  },
  "libraries": {
    "Newtonsoft.Json/10.0.3": {
      "type": "package",
      "serviceable": false,
      "sha512": ""
    }
  }
}

To show how this works, delete the copy of Newtonsoft.Json.dll that we placed next to Program.dll. Then, run dotnet Program.dll

> rm Newtonsoft.Json.dll
> dotnet Program.dll
Error:
  An assembly specified in the application dependencies manifest (Program.deps.json) was not found:
    package: 'Newtonsoft.Json', version: '10.0.3'
    path: 'lib/netstandard1.3/Newtonsoft.Json.dll'

Even though the Program.deps.json file is present, .NET Core needs a little more info about where to probe for aseemblies that match the deps.json file. This config can be specified in one of three ways:

  1. *.runtimeconfig.dev.json. This is typically the best way to configure this. Add a file Program.runtimeconfig.dev.json with the filepath to the package folder. This is like the Program.runtimeconfig.json file, but optional. It typically contains full file paths, so it is not suitable to distribute between machines.

     {
       "runtimeOptions": {
         "additionalProbingPaths": [
           "/Users/nmcmaster/code/packages/"
         ]
       }
     }

  2. Command-line. You can manually specify where to probe for assemblies by using the exec command on dotnet, with the --additionalprobingpath option. Multiple values are allowed.

     > dotnet exec --additionalprobingpath ./packages/ Program.dll

  3. *.runtimeconfig.json. You can add a runtime option to specify new probing paths. These can be relative paths.

     {
       "runtimeOptions": {
         "framework": {
           "name": "Microsoft.NETCore.App",
           "version": "2.0.0"
         },
         "additionalProbingPaths": [
           "./packages/"
         ]
       }
     }


Closing

Most devs don’t need to use these primitives directly. Tools like NuGet, MSBuild, and Visual Studio automatically handle gathering references, C# files, invoking the compiler, attaching the debugger, and more. But I think it’s still useful to know what is going on under the hood. Of course, you can always go deeper. What is actually in a *.dll file? What’s a *.pdb file? What is crossgen and libcoreclr? I’ll leave that for another day.
